Tofu65 2.0 x PBTfans Vior

⌨️Keyboard Discontinued

There are 0 people on the waiting list, click the button below to join! We will notify you by email when the product available

Notify me

Congratulations! You are now on the waiting list, please check your inbox for our confirmation email!

Register Account

Sign In

SKU: TFZH00662
by KBDfans


  • Case: E-coating aluminum case with monochromatic glitter
  • Plate: PC/ Aluminum/ FR4/ Carbon fiber plate
  • PCB: 1.2 mm Flex cut Hot-swap PCB, supports per-key RGB, QMK firmware, VIA support, USB-C port, with daughterboard+JST cable
  • Weight bar: Aluminum material
  • Structure: Top mount, silicone socks, silicone bowl (3 types of structural support)
  • Weight: ≈1.32 kg after assembled with switches and keycaps
  • Dimension: 313.7 mm (length) x 115.7 mm (width) x 18.5 mm (front) x 32.5 mm (back)
  • Feature: Screwless exterior design, the detachable silicon feet hiding all the screws at the bottom
  • Typing angle: 7°
  • Designed by KBDfans and Aiglatson Studio
  • Made in China


  • Aluminum top and bottom case x1
  • Aluminum weight bar x1
  • Plate x1
  • Hot-swap PCB x1
  • USB-C daughterboard x1
  • Silicone bowl x1 set
  • Silicone socks x1 set
  • Foam kit (Case foam x1, PCB foam x1, EVA switch pad x1)
  • Cherry screw-in stabilizers x1 set
  • Screws and rubber feet x1 set

Kindly reminder:

  • The keycaps are not included in this particular item, if you want to buy the keycaps. please click here: PBTfans Vior


  • Start shipping(2023-09-21)
  • Release date: July 14th, 2023
  • Estimated shipping date: September 2023
  • The prototype has been confirmed(2023-06-07)



About the case:

1. Keyboard case - If you see any resemblance of marks or foreign material under 2 mm (tool marks, stain, dent, sand mark, scratch, etc.), you're not eligible for Return & Refund.

2. Brass weight - If you see any resemblance of marks or foreign material under 2 mm (tool marks, stain, dent, sand mark, scratch, etc.), you're not eligible for Return & Refund.

3. Case interior - Based on the production method of anodizing and spraying, the product can lead to some smearing at the surface level, and you'll see some hook marks within the case. Also, the spraying process can not guarantee that the color will look 100% the same on the internal case corners. The color off on the interior case and the interior corners are not eligible for Return & Refund.

4. About the potential coating defects: Because the Faraday cage exists for this type of production method, it's going to be hard to coat the Interior corners perfectly. Insead of kill all the smoothness on the case coating, the interior painting job won't be as perfect as the exterior's.

-Make sure to QC your keyboard case and weight before building it. For any issues besides the three above, please get in touch with our customer support agents to get help.
-For anything built is not eligible for Return & Refund.

Click for more





65% Layout

7 ° typing Angle

Hot-swap & programmable & RGB

3 kinds of structural system support

Multiple materials can be selected

1. Fiberglass
2. Carbon fiber
3. Polycarbonate
4. Aluminum

Hot-swap & QMK open source firmware

Per-key RGB on the top

1.2 mm thickness flex cut PCB

Supports daughter board

Open source QMK firmware that supports VIA online configurator

New design with 3 different mounting styles

Tofu65 2.0 continues the design of the first generation. KBDfans does upgrade the structure this time.

The 2.0 version supports three different mounting styles: Top Mount, Gasket Mount, Silicone bowl Gasket mount(Available in 3 different hardness silicone bowls), which meant to provide three different typing experiences on one keyboard.

Top mount

Silicone bowl gasket

Silicone socks gasket

Explosion Diagram
