Mount Tai GT HE Magnetic Switches

$7.00
SKU: ZH8200

Features

  • One-Piece Housing
    Reduced fit tolerance for higher precision
  • Ultimate Low wobble at bottom-out
    Gauss value variation is less than 3Gs precision supports 0.005RT
  • 0.005rt Ultimate Precision
    Ultimate stepping precision supports 0.005rt, with stable continuous actuation at 0.01rt.
  • Ultra-Stable
    Bigger for extreme performance, bigger for greater stability! We challenge the industry's limits with a massive dust-proof wall that doesn't scrape against keycaps. The 9.35mm extra-large contact surface ensures even force distribution without binding, eliminating the inconsistent feel of off-center presses.
  • Frosted Housing for Maxed-Out RGB!
    The Taishan Magnetic Switch GT features a semi-transparent material with a lightly frosted housing. This design is engineered for brilliant and even light diffusion, allowing the entire switch to illuminate for a stunning, full-bodied RGB effect.

Specs

  • Housing material: pc
  • Stem material: UPE & POM
  • Total travel: 3.4mm
  • Spring: 22mm
  • Initial gauss: 100gs (1.2mm PCB)
  • Bottom-out gauss: 640gs (1.2mm PCB)
  • Initial force: 35gf
  • Bottom-out force: 47gf
  • Magnet: centre & n-pole
  • Pre-lubed: yes
